Application area
Drinking water supply, food processing technology, beverage systems, building services
Product specification
Food-suited material, particularly suitable for beers, soft drinks, water, CO2 and nitrogen
Manufacturing according to FDA and NSF regulations
Easy and quick installation without using tools
Suitable for metal (brass, copper pipes or soft metals) as well as plastic pipes (PA, PE, EVA or PUR)
Can be quickly connected and disconnected many times without problems
Suitable for compressed air and liquids
100 % cleanable according to TRSK 501
Technical specification
Material:
Body: POM (acetal copolymer)
Gasket: NBR
Collet: stainless steel
Colour: gray
Temperature range: -20 to +65 °C
Max. operating pressure: at +20 °C: 10 bar; at +65 °C: 7 bar
Regulations: FDA and NSF
| Item | Image |
Pipe outside Ø inch
|
Einheit Stück
|
Price Euro* | Buy |
|---|
Item
|
|
Pipe outside Ø inch
|
Einheit Stück
|
Price Euro* |
Buy
|
|---|---|---|---|---|---|
| 302970 |
|
3/8" | 1 | 39.00 |
