Product specification
Very small pore size with high flow rate and high uptake capacity for dirt particles at the same time.
The filtration characteristic is depicted by retention of smallest particles (dirt particles).
High pressure loadability with material stability in one. Even under extreme load no fibre release occurs.
Repeated sterilization at highest temperatures allowed.
Permissive temperature load up to max. +500 °C.
The non-woven filter can be cutted, plied and welded without problems.
High corrosion resistance, made of high-quality steel 1.4404
Dimensions: 147.5 x 187.5 mm
| Item | Image |
Filter fineness µm
|
Bubble Point mbar
|
max. Durchfluss Gase1 l/min.
|
Schmutz-Aufnahme mg/cm²
|
Stärke mm
|
Einheit Stück
|
Price Euro* | Buy |
|---|
Item
|
|
Filter fineness µm
|
Bubble Point mbar
|
max. Durchfluss Gase1 l/min.
|
Schmutz-Aufnahme mg/cm²
|
Stärke mm
|
Einheit Stück
|
Price Euro* |
Buy
|
|---|---|---|---|---|---|---|---|---|---|
| 52763 |
|
10 | 37 | 125 | 2 | 0,13 | 1 | 115.00 | |
| 52764 |
|
20 | 18,5 | 400 | 2 | 0,13 | 1 | 126.00 | |
| 52765 |
|
30 | 12,3 | 800 | 2 | 0,13 | 1 | 136.00 | |
| 52766 |
|
10 | 37 | 108 | 3,7 | 0,38 | 1 | 141.00 | |
| 52767 |
|
15 | 24,7 | 180 | 6 | 0,38 | 1 | 159.00 | |
| 52770 |
|
40 | 9,3 | 620 | 11 | 0,65 | 1 | 219.00 |
[1] Air (l/min. x dm2 at 2 mbar)
