Cellular Rubber Plate made of PUR - low density
Product specification
Good deformability
Extremely high volume compressibility
Absolutely free of plasticizers
Good impact resilience and good tear propagation resistance
The foam yellows without changing the physical parameters
Good UV resistance
Good resistance to aging
Excellent resistance to gasoline and oil
Technical specification
Material: PUR (polyurethane ester)
Colour: dark-grey
Temperature range: -40 to +100 °C, for a short time +170 °C
Density: 230 kg/m3
Tensile strength: >1,000 kPa
Compression set: <13 % (DIN 53572)
Design: mixed-cell
Special features: free of plasticizers
General Information
Cellular rubber is a closed-cell, foam-like elastomer that is used, among other things, for sealing, soft storage, insulation, insulation, Entklappern and deadening.
Cellular rubber has no outer skin, making the surface more delicate and easier to damage. Due to the porous but closed-cell structure, the penetration of aqueous medium is not possible.
Cell rubber seals are thus virtually water and air tight.
Foam rubber and cellular rubber are made from the same raw materials, often EPDM, CR, NR, NBR or SBR. Due to different manufacturing processes, however, the material structure of sponge rubber and cellular rubber differs fundamentally.
Item | Image |
Thickness mm
|
Toleranz mm
|
Abmessung mm
|
Einheit Stück
|
Price Euro* | Buy |
---|
Item
|
|
Thickness mm
|
Toleranz mm
|
Abmessung mm
|
Einheit Stück
|
Price Euro* |
Buy
|
---|---|---|---|---|---|---|---|
332262 |
|
0,6 | ±0,1 | 250 x 250 | 1 | 26.00 | |
332263 |
|
0,6 | ±0,1 | 500 x 500 | 1 | 56.00 | |
332264 |
|
0,6 | ±0,1 | 1000 x 1000 | 1 | 110.00 | |
332265 |
|
0,8 | ±0,1 | 250 x 250 | 1 | 33.00 | |
332266 |
|
0,8 | ±0,1 | 500 x 500 | 1 | 65.00 | |
332267 |
|
0,8 | ±0,1 | 1000 x 1000 | 1 | 129.00 | |
332268 |
|
1 | ±0,2 | 250 x 250 | 1 | 35.00 | |
332269 |
|
1 | ±0,2 | 500 x 500 | 1 | 69.00 | |
332270 |
|
1 | ±0,2 | 1000 x 1000 | 1 | 137.00 | |
332271 |
|
1,3 | ±0,2 | 250 x 250 | 1 | 43.00 | |
332272 |
|
1,3 | ±0,2 | 500 x 500 | 1 | 88.00 | |
332273 |
|
1,3 | ±0,2 | 1000 x 1000 | 1 | 178.00 | |
332274 |
|
1,6 | ±0,2 | 250 x 250 | 1 | 45.00 | |
332275 |
|
1,6 | ±0,2 | 500 x 500 | 1 | 95.00 | |
332276 |
|
1,6 | ±0,2 | 1000 x 1000 | 1 | 191.00 | |
332277 |
|
2 | ±0,5 | 250 x 250 | 1 | 48.00 | |
332278 |
|
2 | ±0,5 | 500 x 500 | 1 | 97.00 | |
332279 |
|
2 | ±0,5 | 1000 x 1000 | 1 | 202.00 | |
332280 |
|
3 | ±0,6 | 250 x 250 | 1 | 58.00 | |
332281 |
|
3 | ±0,6 | 500 x 500 | 1 | 116.00 | |
332282 |
|
3 | ±0,6 | 1000 x 1000 | 1 | 238.00 | |
332283 |
|
5 | ±0,7 | 250 x 250 | 1 | 60.00 | |
332284 |
|
5 | ±0,7 | 500 x 500 | 1 | 120.00 | |
332285 |
|
5 | ±0,7 | 1000 x 1000 | 1 | 249.00 |
