Application area
Pharmaceutical industry, soft drink industry, food industry, dairy industry
Product specification
Resistant to animal and vegetable greases and oils.
Resistance to alcohol up to 15 %.
Completely smooth inner surface ensures optimal emptiing of residual charge and reliable cleaning at change of charge.
Liner is physiologically absolutely safe, it does not contain any extractable constituents, thus the tubing is best suited for conveyance of high-quality products.
Tasteless and odorless.
Resistant to weather and aging.
Steam strippable against bacteria up to max. +120 °C or washable with hot water and ordinary household cleaners.
Technical specification
Material:
Liner: NBR (butadiene-acrylonitrile rubber)
Colour:
Liner: white, mirror-smooth
Jacket: blue, textile imprint
Temperature range: -25 to +90 °C, for a short time for cleaning +120 °C (30 min.)
Max. operating pressure: 10 bar at +20 °C
Bursting pressure: 30 bar at +20 °C
Regulations: FDA 21 CFR §177.2600, BfR XXI Cat. 2
Tubing imprint: milk tubing, PN 10 bar, FDA, food symbol
| Item | Image |
Inside Ø mm
|
Außen-Ø mm
|
max. Betr.-Druck1 bar
|
Einheit m
|
Price Euro* | Buy |
|---|
Item
|
|
Inside Ø mm
|
Außen-Ø mm
|
max. Betr.-Druck1 bar
|
Einheit m
|
Price Euro* |
Buy
|
|---|---|---|---|---|---|---|---|
| 340008 |
|
32 | 44 | 10 | 1 | 95.00 |
[1] at +20 °C
