Product specification
Flexible and resistant material, resistant to aging and abrasion, rugged and pressure-proof, inside and outside smooth, hardly inflammable, to a high degree resistant to hot water and oil (e.g. heating oil) at flow, sterilizable, no change of material by light or atmospheric oxygen.
Technical specification
Material: PVC-P (polyvinyl chloride, soft)
Colour: crystal-clear
Shore hardness A: 75° ±3° (DIN 53505)
Density: 1.25 g/cm3
Tensile strength: 190 kp/cm2
Elongation at break: 390 %
Tolerance: DIN ISO 3302-1 E2
| Item | Image |
Inside Ø mm
|
Außen-Ø mm
|
max. Betr.-Druck1 bar
|
min. Biegeradius mm
|
Einheit m
|
Price Euro* | Buy |
|---|
Item
|
|
Inside Ø mm
|
Außen-Ø mm
|
max. Betr.-Druck1 bar
|
min. Biegeradius mm
|
Einheit m
|
Price Euro* |
Buy
|
|---|---|---|---|---|---|---|---|---|
| 27356 |
|
6 | 10 | 3 | 20 | 5 | 74.00 | |
| 27357 |
|
6 | 10 | 3 | 20 | 10 | 127.00 | |
| 27359 |
|
8 | 12,6 | 3 | 30 | 5 | 86.00 | |
| 27360 |
|
8 | 12,6 | 3 | 30 | 10 | 143.00 | |
| 27362 |
|
10 | 15,4 | 3 | 40 | 5 | 113.00 | |
| 27363 |
|
10 | 15,4 | 3 | 40 | 10 | 179.00 | |
| 27365 |
|
13 | 18,8 | 2 | 50 | 5 | 118.00 | |
| 27366 |
|
13 | 18,8 | 2 | 50 | 10 | 190.00 | |
| 27368 |
|
16 | 23 | 2 | 70 | 5 | 130.00 | |
| 27369 |
|
16 | 23 | 2 | 70 | 15 | 266.00 | |
| 27370 |
|
19 | 26 | 2 | 80 | 5 | 211.00 | |
| 27371 |
|
19 | 26 | 2 | 80 | 15 | 397.00 | |
| 27372 |
|
25 | 34 | 1 | 110 | 5 | 211.00 | |
| 27373 |
|
25 | 34 | 1 | 110 | 15 | 397.00 | |
| 27374 |
|
32 | 41 | 1 | 130 | 5 | 253.00 | |
| 27375 |
|
32 | 41 | 1 | 130 | 10 | 452.00 | |
| 27376 |
|
38 | 48 | 1 | 200 | 5 | 334.00 | |
| 27377 |
|
38 | 48 | 1 | 200 | 10 | 501.00 | |
| 27378 |
|
45 | 57 | 1 | 200 | 5 | 373.00 | |
| 27379 |
|
45 | 57 | 1 | 200 | 10 | 540.00 |
[1] at +20 °C
