Product specification

Liner is inert and neutral, tasteless and odourless.

Liner does not absorb liquids.

Liner meets the requirements of FDA, USDA, National Formulary, and the USP-Standards for food, beverages, pharmaceutical products, laboratory and medical equipment.

Non-toxic.

Jacket is resistant to abrasion and aging.

Neither the jacket nor the liner contain plasticizers or vinyl chloride.

Technical specification

Material:

Liner: LDPE (low density polyethylene, highly cross-linked)

Jacket: EVA (ethylene vinyl acetate, highly cross-linked)

Colour: translucent

Temperature range: -35 to +95 °C

Embrittlement temperature: -51 °C

Hemolysis: none

Close menu

No additional information available.

Item	Inside Ø mm	Außen-Ø mm	max. Betr.-Druck¹ bar	Einheit m	Price Euro*
28019	1,6	4,8	6,5	5	158.00
28020	1,6	4,8	6,5	15	387.00
28021	3,2	4,8	3,3	5	160.00
28022	3,2	4,8	3,3	15	456.00
28023	3,2	6,4	5,5	5	182.00
28024	3,2	6,4	5,5	15	464.00
28027	4,8	6,4	3	5	182.00
28028	4,8	6,4	3	15	464.00
28029	4,8	7,9	4,5	5	240.00
28030	4,8	7,9	4,5	15	572.00
28031	6,4	9,5	4,5	5	261.00
28032	6,4	9,5	4,5	15	626.00
28035	7,9	11,1	4,2	5	325.00
28036	7,9	11,1	4,2	15	716.00
28037	9,5	12,7	4	5	325.00
28038	9,5	12,7	4	15	716.00
28039	9,5	15,9	5	5	380.00
28040	9,5	15,9	5	15	862.00
28041	12,7	15,9	2,5	5	570.00
28042	12,7	15,9	2,5	15	1,293.00
28045	12,7	19	4	5	729.00
28046	12,7	19	4	15	1,750.00
28047	19	25,4	3	15	2,532.00
28048	25,4	31,8	2	15	3,368.00
