PTFE Chemical Tubing - standard
General Information
For use in analytical technology, biotechnology, medical engineering, battery technology, microelectronics, process technology and chemical process engineering.
For transport of acids, alkalis, salt solutions, including solutions with a high chloride content, and solvents, including halogenated ones. For use in low pressure components of HPLC systems, particularly in metal-free set-ups and for low-pressure liquid chromatography.
Transport hose for aggressive chemicals
Very good chemical resistance towards most aggressive media
Very high temperature resistance
Very good coefficient of sliding friction, lowest friction coefficient of all fluoroplastics
Antiadhesive surface
Very good dielectric properties, independent of frequency and temperature
Very good insulating properties, even under humid conditions
Excellent UV and weather resistance
Low mechanical strength properties (unless manufactured with additives or fillers)
No water absorption
Very high gas-tightness (low gas permeability)
High tracking resistance
Non-flammable
Flexible, impact resistant and resistant to aging
Free of extractable components, physiologically safe and biocompatible.
Free from plasticizers, latex and silicone
PTFE is a fluoroplast with excellent resistance to acids, alkalis, solvents and gases. Heat resistant up to +260 °C, depending on mechanical load and chemical exposure. PTFE is not resistant to some fluorine compounds as well as molten alkali metals at higher temperatures.
Material: PTFE (polytetrafluoroethylene)
Colour: milky, weakly translucent
Temperature range: -200 to +260 °C, for a short time +280 °C
Tolerances inside Ø:
0 - 0.9 mm: ±0.07 mm
1 - 2.9 mm: ±0.15 mm
3 - 5 mm: ±0.20 mm
5 - 7 mm: ±0.25 mm
7 - 10 mm: ±0.30 mm
15 - 20 mm: ±0.40 mm
Tolerances wall thickness:
0.1 - 0.3 mm: ±0.07 mm
0.3 - 0.6 mm: ±0.10 mm
0.6 - 1.0 mm: ±0.15 mm
1.0 - 2.0 mm: ±0.20 mm
Item | Image |
Inside Ø mm
|
Außen-Ø mm
|
Einheit m
|
Price Euro* | Buy |
---|
Item
|
|
Inside Ø mm
|
Außen-Ø mm
|
Einheit m
|
Price Euro* |
Buy
|
---|---|---|---|---|---|---|
92520 |
|
0,3 | 0,8 | 3 | 11.00 | |
92521 |
|
0,3 | 0,8 | 9 | 25.00 | |
92522 |
|
0,3 | 1,75 | 3 | 15.00 | |
92523 |
|
0,3 | 1,75 | 9 | 36.00 | |
92524 |
|
0,4 | 0,9 | 3 | 11.00 | |
92525 |
|
0,4 | 0,9 | 9 | 25.00 | |
92528 |
|
0,5 | 1 | 3 | 13.00 | |
92529 |
|
0,5 | 1 | 9 | 29.00 | |
92526 |
|
0,5 | 1,5 | 3 | 19.00 | |
92527 |
|
0,5 | 1,5 | 9 | 43.00 | |
9319616 |
|
0,5 | 3 | 3 | 25.00 | |
9319626 |
|
0,5 | 3 | 30 | 198.00 | |
92530 |
|
0,6 | 1,2 | 3 | 13.00 | |
92531 |
|
0,6 | 1,2 | 9 | 29.00 | |
92532 |
|
0,7 | 1,3 | 3 | 15.00 | |
92533 |
|
0,7 | 1,3 | 9 | 37.00 | |
92534 |
|
0,7 | 1,6 | 3 | 13.00 | |
92535 |
|
0,7 | 1,6 | 9 | 30.00 | |
92536 |
|
0,7 | 2 | 3 | 21.00 | |
92537 |
|
0,7 | 2 | 9 | 48.00 | |
92538 |
|
0,9 | 1,5 | 3 | 14.00 | |
92539 |
|
0,9 | 1,5 | 9 | 35.00 | |
92540 |
|
0,9 | 1,7 | 3 | 19.00 | |
92541 |
|
0,9 | 1,7 | 9 | 43.00 | |
92542 |
|
1 | 1,5 | 3 | 14.00 |
